Bristan – 1901 Concealed Dual Control Three Handle Thermostatic Shower Valve – Chrome

Bristan – 1901 Concealed Dual Control Three Handle Thermostatic Shower Valve – Chrome – N2-SHC3STP-C

The 1901 shower valve has a classic and simple traditional design. Brass construction provides superior durability and conforms to BS EN 248 standards. This amazing valve trim includes lots of features and is suitable for all plumbing systems, an amazing addition to any bathroom.

Features

• Finish: Chrome
• Product Type: Traditional
• Construction: Body is of brass construction
• Valve type: 2 x ¼ turn ¾“ ceramic disc on/off control with thermostatic temperature control
• Supply: Gravity (when pumped) and pressurised
• Inlet Connections: 15mm compression
• Outlet Connection: 15mm compression
• Working Pressures: Min 1.0bar, Max 8.0bar
• Dimensions for Fitting: 150mm inlet centres

Additional Information

• Dual control – flow and temperature are controlled by separate handles, giving accurate control of both.
• Ceramic disc flow valve giving low maintenance and an easy ¼ turn on/off and flow control.
• Thermostatic cartridge maintains showering temperature to +/- 1oC by compensating for changes in the incoming water temperature and pressure giving the stable outlet temperature. Designed to meet requirements of BS EN 1287:1999 and BS EN 1111:1999.
• Automatic shut off in the event of hot or cold water supply failure, thus reducing the risk of scalding.
• Factory set to a maximum of 42 oC to eliminate the ability to select an unsafe temperature, this can be adjusted to suit user preference.
• Swivel inlet elbows with 150mm centres, valve can be fed from top, bottom or rear
• Hose outlet included
• Chrome plated to BS EN 248.

Guarantee: 5 years covering manufacturing faults
